Deco Display Fabric AA201

Deco Display Fabric AA201 is a high-quality polyester fabric perfect for creating displays, pop-ups, and backdrops. It features a warp-knitted 3 bar weave method and a weight of 220±10gsm, ensuring its stability and consistency. The fabric's thickness of 450±50μm offers excellent opacity (≥80%) with a whiteness of 160±10, resulting in vivid and eye-catching prints. This fabric is perfect for sublimation printing with recommended fixation temperatures between 190-200℃ for 45 seconds. Furthermore, the fabric's elasticity of 3-5% makes it suitable for various irregular display forms. This ultra-high cost-effectiveness front light box fabric provides a flat fabric surface, stable and consistent printing quality, making it perfect for use in indoor and outdoor front display advertisements (under mild weather conditions) using the recommended printing methods of Dye-sub Direct and Dye-sub Transfer.

CONTACT NOW

Specification

Specifications of Deco Display Fabric AA201

Base Material100% PolyesterDIN 60001, ASTM D7641
Yarn75D*40D*40DDIN EN 2060, ASTM D1907
Weave MethodWarp-knitted 3 bar---
Weight220±10gsmISO536
Thickness450±50μmISO534
Opacity≥80%ISO2471
Whiteness160±10ISO11475
ColorL:88.0±2.0; a:9.0±2.0; b:-20.0±2.0---
Gloss[60°]4±2---
ElasticityWarp:(6±3)% Weft:(3±2)%Length*Width=200*50mm,Speed=100mm/min,Tension=20N
Shrinkage≤2%200°C,45s
Yellowing △E≤2200°C,45s
Flame ResistanceDIN 4102-1 B1, NFPA 701DIN 4102-1 B1, NFPA 701
Recommend Fixation Temperature190-200℃,45s---
Yellowing Temperature≥210℃SUPRKC REX-C400,30s


Size

Deco Display Fabric AA201 Size
Width1.60 m/2.60 m/3.20 mStandardDIN EN ISO 3759, ASTM D751-2006
Length50mStandardDIN EN ISO 3759, ASTM D751-2006


Compatible Inks

Compatible Inks
Dye-sub TransferDye-sub Direct
