Piano Backdrops Fabric AA701-4

Piano Backdrops Fabric AA701-4 is an excellent choice for creating stunning displays in various settings such as exhibitions, pop-ups, frames, and backdrops. Its warp-knitted 2 bar method of processing 100% polyester ensures exceptional durability and strength. With a weight of 250±15gsm and a thickness of 410±40μm, it offers excellent coverage for an eye-catching display. The fabric boasts an opacity of over 99% and a whiteness of 160±10, providing a professional look. Available in sizes of 1.60 m/2.60 m/3.20 m with a length of 50 m, it has minimal shrinkage, ≤3%, and an elasticity of Warp:(4±2)% and Weft:(4±2)%, making it versatile enough for any display need. Recommended to fix at 190-200℃ for 45s and has a yellowing temperature of ≥210℃.

CONTACT NOW

Specification

Specifications of Piano Backdrops Fabric AA701-4

Base Material100% PolyesterDIN 60001, ASTM D7641
Yarn75D*55DDIN EN 2060, ASTM D1907
Weave MethodWarp-knitted 2 bar---
Weight250±15gsmISO536
Thickness410±40μmISO534
Opacity>99%ISO2471
Whiteness160±10ISO11475
ColorL:89.0±2.0; a:8.5±2.0; b:-19.0±2.0---
Gloss[60°]3±1---
ElasticityWarp:(4±2)% Weft:(4±2)%Length*Width=200*50mm,Speed=100mm/min,Tension=20N
Shrinkage≤3%200°C,45s
Yellowing △E≤2200°C,45s
Flame ResistanceDIN 4102-1 B1,NFPA 701DIN 4102-1 B1,NFPA 701
Recommend Fixation Temperature190-200℃,45s---
Yellowing Temperature≥210℃SUPRKC REX-C400,30s


Size

Piano Backdrops Fabric AA701-4 Size
Width1.60 m/2.60 m/3.20 mStandardDIN EN ISO 3759, ASTM D751-2006
Length50 mStandardDIN EN ISO 3759, ASTM D751-2006


Compatible Inks

Compatible Inks
Dye-sub TransferDye-sub Direct
