Triple White Twill Backlit Fabric AA576

Introducing Triple White Twill Backlit Fabric AA576, an exceptional fabric material designed for backlit applications such as LED light boxes, backdrops, pop-up displays, and SEG. Made from 100% polyester using a woven construction with 75D*T800 yarn, this fabric offers superior durability. It has a weight of 190±10gsm and a thickness of 270±30μm, providing excellent opacity of 85±5 and a whiteness value of 155±10. The fabric features a color value of L: 89.0±2.0; a: 7.5±2.0; b: -17.0±2.0. The Triple White Twill Backlit Fabric AA576 is available in a width of 1.60 m, 2.60 m, and 3.20 m, with lengths of 50 m or 100 m. This fabric maintains elasticity of 4%±2%, has a shrinkage rate of ≤3%, and requires a fixation temperature of 190-200℃ for 45s with a yellowing temperature of ≥210℃.

CONTACT NOW

Specification

Specifications of Triple White Twill Backlit Fabric AA576

Base Material100% PolyesterDIN 60001, ASTM D7641
Yarn75D*T800DIN EN 2060, ASTM D1907
Weave MethodWoven---
Weight190±10gsmISO536
Thickness270±30μmISO534
Opacity85±5ISO2471
Whiteness155±10ISO11475
ColorL:89.0±2.0; a:7.5±2.0; b:-17.0±2.0---
Gloss[60°]4±2---
Elasticity4%±2%Length*Width=200*50mm,Speed=100mm/min,Tension=20N
Shrinkage≤3%200°C,45s
Yellowing △E≤2200°C,45s
Flame ResistanceDIN 4102-1 B1,NFPA 701DIN 4102-1 B1,NFPA 701
Recommend Fixation Temperature190-200℃,45s---
Yellowing Temperature≥210℃SUPRKC REX-C400,30s


Size

Triple White Twill Backlit Fabric AA576 Size
Width1.60 m/2.60 m/3.20 mStandardDIN EN ISO 3759, ASTM D751-2006
Length50 m/100 mStandardDIN EN ISO 3759, ASTM D751-2006


Compatible Inks

Compatible Inks
Dye-sub TransferDye-sub Direct
